Kaichi Nr.: MA-013-32M
Brand:KaiChi
Radiator Type:Brazed Aluminum Core
Size In Inch:26-7/16 In X 14-7/8 In X 1-1/4 In
Size In MM:672mm X 378mm X PA32
Min Order Qty:10pcs
Payment Term: T/T
Incoterm: FOB,CIF
Shipping Ports: Shenzhen or Ningbo in China
Item Specifics:
| Part Type: | Mechanical Radiator | Brand: | KaiChi |
| Manufacturer Warranty: | 1 Year | Manufacturer Part Number: | MA-013-32M |
| Height: | 26-7/16 In./672mm | Width: | 14-7/8 In./378mm |
| Thickness: | 1-1/4 In./32mm | Inlet Diameter: | 1-5/16 In./34mm |
| Outlet Diameter: | 1-5/16 In./34mm | Tank Material: | Plastic |
| Core Material: | Aluminum | Trans Oil Cooler: | None |
| Trans Oil Cooler Central Distance: | None | Rows: | 2 |
Applications：
| Mazda 3 BK14 1.3L 2003-2009 |
| Mazda 3 BK14 1.6L 2003-2009 |
| Mazda 3 BK 1.6DI Turbo 2004-2009 |
| Mazda 3 BK 1.6MZ CD 2004-2009 |
| Mazda 3 BK 2.0 BKEP 2003-2009 |
| Mazda 3 BK14 2.0MZR CD 2006-2009 |
| Mazda 3 BK14 2.3 MPS Turbo 2006-2009 |
| Mazda 3 Saloon BK12 1.6L 2004-2009 |
| Mazda 3 Saloon BK12Y 1.6 DI Turbo 2004-2009 |
| Mazda 3 Saloon BK 2.0L 2003-2006 |
| Mazda 3 Saloon BK 2.0 BKEP 2003-2009 |
| Mazda 3 Saloon BK12 2.0 MZR-CD 2006-2009 |
| Mazda 5 CR19 1.8L 2005-2010 |
| Mazda 5 CR19 2.0 CD 2005-2010 |
| Mazda 5 CR19 CREW 2.0L 2005-2010 |
| Mazda 5 CW 1.6CD 2010- |
| Mazda 5 CW CWEFW 2.0 2010- |
| VOLVO C30 553 1.6L 2006-2012 |
| VOLVO C30 553 1.8L 2006-2012 |
| VOLVO C30 553 1.8 FlexFuel 2007-2012 |
| VOLVO C30 553 2.0L 2006-2012 |
| VOLVO C30 553 2.0 FlexFuel 2010-2012 |
| VOLVO S40 I 644 1.6L 1995-2003 |
| VOLVO S40 I 644 1.8L 1995-2003 |
| VOLVO S40 I 644 1.8i 1998-2003 |
| VOLVO S40 I 644 2.0L 1995-2003 |
| VOLVO S40 II 544 1.6L 2005-2012 |
| VOLVO S40 II 544 1.8L 2004-2010 |
| VOLVO S40 II 544 1.8 FlexFuel 2006-2010 |
| VOLVO S40 II 544 2.0L 2006-2010 |
| VOLVO S40 II 544 2.0D 2004-2010 |
| VOLVO V40 Station Wagon 645 1.6L 1999-2004 |
| VOLVO V40 Station Wagon 645 1.8L 1999-2004 |
| VOLVO V40 Station Wagon 645 1.8i 1998-2004 |
| VOLVO V40 Station Wagon 645 2.0L 1995-2004 |
| VOLVO V50 545 1.6L 2005-2012 |
| VOLVO V50 545 1.8L 2004-2010 |
| VOLVO V50 545 1.8 FlexFuel 2005-2010 |
| VOLVO V50 545 2.0L 2006-2012 |
| VOLVO V50 545 2.0D 2004-2010 |
| VOLVO V50 545 2.0 FlexFuel 2010-2012 |
| Ford C-MAX DM2 1.6L 2007-2010 |
| Ford C-MAX DM2 1.6TDCi 2007-2010 |
| Ford C-MAX DM2 1.8L 2007-2010 |
| Ford C-MAX DM2 1.8 Flexifuel 2007-2010 |
| Ford C-MAX DM2 1.8 TDCi 2007-2010 |
| Ford C-MAX DM2 2.0L 2007-2010 |
| Ford C-MAX DM2 2.0CNG 2009-2010 |
| Ford C-MAX DM2 2.0LPG 2008-2010 |
| Ford C-MAX DM2 2.0TDCi 2007-2010 |
| Ford Focus C-MAX DM2 1.6L 2003-2007 |
| Ford Focus C-MAX DM2 1.6TDCi 2003-2007 |
| Ford Focus C-MAX DM2 1.6Ti 2004-2007 |
| Ford Focus C-MAX DM2 1.8L 2003-2007 |
| Ford Focus C-MAX DM2 1.8 Flexifuel 2006-2007 |
| Ford Focus C-MAX DM2 1.8 TDCi 2005-2007 |
| Ford Focus C-MAX DM2 2.0L 2004-2007 |
| Ford Focus C-MAX DM2 2.0 TDCi 2003-2007 |
| Ford Focus II Convertible 1.6L 2006-2010 |
| Ford Focus II Convertible 2.0L 2006-2010 |
| Ford Focus II Convertible 2.0TDCi 2006-2010 |
| Ford Focus II DA/HCP/DP 1.4L 2004-2012 |
| Ford Focus II DA/HCP/DP 1.6L 2004-2012 |
| Ford Focus II DA/HCP/DP 1.6LPG 2009-2011 |
| Ford Focus II DA/HCP/DP 1.6 TDCi 2004-2012 |
| Ford Focus II DA/HCP/DP 1.6 Ti 2004-2012 |
| Ford Focus II DA/HCP/DP 1.8L 2006-2012 |
| Ford Focus II DA/HCP/DP 1.8 Flexifuel 2006-2012 |
| Ford Focus II DA/HCP/DP 1.8 TDCi 2005-2012 |
| Ford Focus II DA/HCP/DP 2.0L 2004-2012 |
| Ford Focus II DA/HCP/DP 2.0 CNG 2009-2011 |
| Ford Focus II DA/HCP/DP 2.0 LPG 2008-2011 |
| Ford Focus II DA/HCP/DP 2.0 TDCi 2004-2012 |
| Ford Focus II DA/HCP/DP 2.5 RS 2009-2011 |
| Ford Focus II DA/HCP/DP 2.5 RS 500 2010-2011 |
| Ford Focus II DA/HCP/DP 2.5 ST 2005-2012 |
| Ford Focus II Saloon DB/FCH/DH 1.4L 2005-2012 |
| Ford Focus II Saloon DB/FCH/DH 1.6L 2005-2012 |
| Ford Focus II Saloon DB/FCH/DH 1.6TDCi 2005-2012 |
| Ford Focus II Saloon DB/FCH/DH 1.6Ti 2005-2012 |
| Ford Focus II Saloon DB/FCH/DH 1.8L 2006-2012 |
| Ford Focus II Saloon DB/FCH/DH 1.8 Flexifuel 2006-2011 |
| Ford Focus II Saloon DB/FCH/DH 1.8 TDCi 2005-2012 |
| Ford Focus II Saloon DB/FCH/DH 2.0L 2005-2011 |
| Ford Focus II Saloon DB/FCH/DH 2.0 TDCi 2005-2012 |
Cross Reference:
Cross Reference information is provided as a guide only. Please refer to the Applications, Part Specifications and Drawings to verify fit.
| VALEO Europe | 733254 |
| VALEO Europe | 734320 |
| DENSO Europe | DRM10074 |
| NRF | 55327A |
| AKS DASIS | 090011N |
| AVA QUALITY COOLING | FDA2370 |
| NISSENS Number | 62017A |
OEM Part Number:
| 1230987 |
| 1251092 |
| 1300467 |
| 1305492 |
| 1306399 |
| 1306756 |
| 1309414 |
| 1311211 |
| 1318177 |
| 1320715 |
| 1323756 |
| 1330989 |
| 1352293 |
| 1354177 |
| 1354178 |
| 1357325 |
| 1366834 |
| 1374402 |
| 1376193 |
| 1388579 |
| 1426142 |
| 1431190 |
| 3041045 |
| 30665934 |
| 30665936 |
| 30683034 |
| 30683522 |
| 30683523 |
| 30741044 |
| 30741045 |
| 30741094 |
| 3M5H8005TE |
| 3M5H8005TF |
| 3M5H8005TG |
| 3M5H8005TH |
| 3M5H8005TJ |
| 3M5H8005TK |
| 3M5H8005TL |
| 3M5H8005TM |
| 3M5H8005RG |
| 3M5H8005RH |
| 3M5H8005RJ |
| 3M5H8005RK |
| 6840253 |
| 8603244 |
| 8603620 |
| 8603811 |
| 8603126 |
| 8603254 |
| 8603621 |
| 9463247 |
| L33X-15-200 |
| Y601-15-200 B |
| Y601-15-200 C |
| Y601-15-200 D |
| Y601-15-200 E |
| Z602-15-200C |
| Z60215200B |
| Z603-15-200 |
