Kaichi Nr.: IS-034-26
Brand:KaiChi
Radiator Type:Brazed Aluminum Core
Size In Inch:16-1/2 In X 25-1/2 In X 1 In
Size In MM:420mm X 648mm X PA26
Min Order Qty:10pcs
Payment Term: T/T
Incoterm: FOB,CIF
Shipping Ports: Shenzhen or Ningbo in China
Item Specifics:
| Part Type: | Auto Radiator | Brand: | KaiChi |
| Manufacturer Warranty: | 1 Year | Manufacturer Part Number: | IS-034-26 |
| Height: | 16-1/2 In./420mm | Width: | 25-1/2 In./648mm |
| Thickness: | 1 In./26mm | Inlet Diameter: | 1-1/2 In./38mm |
| Outlet Diameter: | 1-1/2 In./38mm | Tank Material: | Plastic |
| Core Material: | Aluminum | Trans Oil Cooler: | Brass/Concentric |
| Trans Oil Cooler Central Distance: | 13-3/4 In./350mm | Rows: | 1 |
Applications：
| Isuzu D-Max TFS87 1.9TD RZ4E-TC 2016-2020 |
| Isuzu D-Max TFS86TT 2.5D Twin Turbo 2012-2020 |
Cross Reference:
Cross Reference information is provided as a guide only. Please refer to the Applications, Part Specifications and Drawings to verify fit.
OEM Part Number:
| 8983355661 |
| 8981372764 |
