Kaichi Nr.: GM-194-16
Brand:KaiChi
Radiator Type:Brazed Aluminum Core
Size In Inch:23-5/8 In x 16-7/16 In x 5/8 In
Size In MM:600mm x 418mm x PA16
Min Order Qty:10pcs
Payment Term: T/T
Incoterm: FOB,CIF
Shipping Ports: Shenzhen or Ningbo in China
Item Specifics:
| Part Type: | Auto Radiator | Brand: | KaiChi |
| Manufacturer Warranty: | 1 Year | Manufacturer Part Number: | GM-194-16 |
| Height: | 23-5/8 In./600mm | Width: | 16-7/16 In./418mm |
| Thickness: | 5/8 In./16mm | Inlet Diameter: | 1-5/16 In./34mm |
| Outlet Diameter: | 1-5/16 In./34mm | Tank Material: | Plastic |
| Core Material: | Aluminum | Trans Oil Cooler: | Brass/Concentric |
| Trans Oil Cooler Central Distance: | 10 In./254mm | Rows: | 1 |
Applications：
| Chevrolet Aveo Base L4 1.6L 2004,2008 |
| Chevrolet Aveo LS L4 1.6L 2004-2008 |
| Chevrolet Aveo LT L4 1.6L 2005-2008 |
| Chevrolet Aveo Special Value L4 1.6L 2005-2006 |
| Chevrolet Aveo T200 1.4L 2003-2007 |
| Chevrolet Aveo T200 1.5L 2004-2008 |
| Chevrolet Aveo5 LS L4 1.6L 2006-2008 |
| Chevrolet Aveo5 LT L4 1.6L 2006-2008 |
| Chevrolet Aveo5 Special Value L4 1.6L 2007-2008 |
| Pontiac G3 Base L4 1.6L 2007-2008 |
| Pontiac Wave (Canada) Base L4 1.6L 2005-2008 |
| Pontiac Wave (Canada) SE L4 1.6L 2007-2008 |
| Pontiac Wave5 (Canada) Base L4 1.6L 2005-2007 |
| Suzuki Swift Base L4 1.5L 2007-2009 |
| Suzuki Swift+ (Canada) Base L4 1.6L 2004-2008 |
| Suzuki Swift+ (Canada) S L4 1.6L 2004-2008 |
| Daewoo Kalos F14D3 1.4L 2003-2004 |
Cross Reference:
Cross Reference information is provided as a guide only. Please refer to the Applications, Part Specifications and Drawings to verify fit.
| DPI | 2873 |
| SPI | CU2873 |
| APDI | 8012873 |
| TYC | 2873 |
| CSF | 3256 |
| VALEO | 376166 |
| DENSO | 221-9020 |
| Vista-Pro | 433985 |
| NRF | 53639 |
| AVA QUALITY COOLING | DW2068 |
| NISSENS Number | 61637 |
| Partslink | GM3010447 |
OEM Part Number:
| 42438322 |
| 42438331 |
| 42438332 |
| 96443478 |
| 96443479 |
| 96536526 |
| 96536527 |
| 96816484 |
| 96817345 |
| 96887367 |
| 96887368 |
| P96536526 |
